Power:7W
LED:CREE/OSRAM/LUMINUS/CITIZEN
CRI: 80 / 90
SDCM: 3 / 5
CCT: 2700K / 3000K / 4000K / 5700K/RGB 3in1/RGBW 4in1
Control: Remote / On-Off
Input Voltage:DC24V/DC12V
Dimming: DALI / DMX512 / 0-10V / 1-10V / Triac
Beam Angle: SMD: 4°/6°/9° /10°/15°/25° /30° /40° /60°
COB: 15°/24° /38°（Lens）,10°/23°/38°（Reflector Cup）
Material: 316L Stainless steel
Accessories: Honeycomb louver/Half shading
Waterproof: IP68
Certification: CE EMC LVD, ROHS, IP68 etc.
Warranty: 3-5 Years/
| Model No.: | Power | LED QTY | LED Color | Beam Angle | Input Volt. |
| DM-UW800306 | 7W | 3PCS | 3000K/4000K /5000K/5700K | 10°/15°/25° /30° /40° /60°/10°*45°/20°*65° | DC24V |
| DM-UW800108 | 1PCS | 4°/6°/9° | |||
| DM-UW800110 | 15°/24° /38° （Lens） | ||||
| DM-UW800111 | 10°/23° /38° （Reflector Cup） | ||||
| DM-UW800309 | 3PCS | RGBW 4in1 DMX512 | 25°/40° /60°/10°*22° /12°*45°/15°*55° |
Front Cover&Housing:Stainless steel SUS 316L#
Lens：Optical lens，efficiency≥85%
Driver:Constant voltage input.Constant current output.
Glass:Step tempered glass.
Mounting sleeve:ABS
Dimmable: Triac/Dali/1-10V/PWM/DMX512.
Power Cable:H07RN-F 2×1.0mm2 L=3m(low voltage).
