BELITE IP66 5W COB led path light 220V/24V landscape spot light

Power:1W~15W

LED:CREE/OSRAM

CRI:  80 / 90

SDCM: 3 / 5

CCT: 2700K / 3000K / 4000K / 6000K/RGB 3in1/RGBW 4in1

Control: Remote / On-Off

Input Voltage:DC24V/AC220V

Dimming: DALI / DMX512 / 0-10V / 1-10V / Triac

Beam Angle: 15°/24°/36°  /60°

5°/8°/10° /12°/17°/25°/40°/60°

Material: CNC 6063# aluminum

Accessories: Spike/Cylindrical Hood

Waterproof: IP66

Certification: CE EMC LVD, ROHS, IP66 etc.

Warranty: 3-5 Years

Download
Material Specifications
Model No.:PowerLED QTYLED BrandLED ColorBeam AngleInput Volt.
LM-GD6901088W/10W1PCS

CREE

3000K/4000K

/5000K/5700K

15°/24°/36° /60°

AC220V

LM-GD6901077W-10WDC24V
LM-GD6903066W/8W3PCS

CREE/OSRAM

5°/8°/10° /12°

/17°/25°/40°/60°

AC220V

LM-GD6903077W-10WDC24V
LM-GD550105

TYANSHINE

RGBW 4in1 DMX512

DC24V


Housing: CNC 6063# aluminum. Matt sliver/black anodized Finish pr powder coated

Lens:Optical lens,efficiency≥85%

Glass Cover:Tempered glass.T=4mm

Driver:Constant voltage input.Constant current output.

Dimmable: Triac/Dali/1-10V/PWM/DMX512.

Power Cable:H05RN-F 2×1.0mm2 L=0.5m(low voltage).H05RN-F 3×1.0mm²  L=0.5m(high voltage)

                     H05RN-F 2×1.0+3×0.5mm²  L=0.5m(RGBW 4in1 DMX512)

Working Temperature:-20 to 40°C.

Base:Aluminum

Spike:ABS

Mounting Type:U bracket&mounting plate for solid ground,spike for soft ground.


Parameter Data

BELITE IP66 5W COB led path light 220V/24V landscape spot light

Installation Instruction
